L.U.C.A.S 2000 Manual 1.0
9 Technische Daten
L.U.C.A.S 2000 Subwoofer
Ein- /Ausgänge:
Line In: XLR female (pin 1= Ground; 2= +, 3= -)
Bauart Eingang: Elektronisch symmetriert & floating
Eingangsimpedanz: 47 k Ohm
Empfindlichkeit: 0 dBV (=1V) (Gain Regler voll
aufgedreht)
Max. Eingangspegel: + 14 dB
Parallel Out: XLR male (pin 1= Ground; 2=+, 3= -)
Lautsprecherausgänge: Speakon
®
NL 4
(pin 1+= +, 1-= -)
Verstärker:
Ausgangsleistung Subwoofer: 1200 W RMS
Ausgangsleistung Satelliten: 2x 400 W RMS
Schutzschaltungen: Subsonic Filter, Multiband
Limiter
Aktive Frequenzweiche: Trennfrequenz: 110 Hz
Lautsprecherbestückung: Lautsprecher: 1x 18"
Frequenzgang Subwoofer: 40 Hz -110 Hz, ± 3 dB
Schalldruck 1W / 1m: 103 dB (half space)
Max. Schalldruck / 1m: 131 dB @ 10% THD
(half space)
Gewichte und Maße:
Gewicht: 56 kg / 123.2 lbs.
Maße inklusive Rollen (BxHxT):
52 cm x 63 cm x 73 cm • 20 1/2" x 24 7/8" x 28 3/4"
L.U.C.A.S 2000 Satellite
Eingänge:
Lautsprecher Eingang: Speakon NL 4
(pin 1+= +, 1-= -)
Lautsprecherbestückung:
Lautsprecher: 1x 12" HK Audio Custom
Treiber: 1x 1" B&C
Directivity: 60°x 40° CD Horn
Gesamtnennimpedanz: 8 Ohm
Nominale Belastbarkeit: 400 W RMS
Schalldruck 1W / 1m: 105 dB (halfspace)
Max. Schalldruck / 1m: 126 dB @ 10% THD
(half space)
Frequenzgang (über aktive Frequenzweiche):
110 Hz - 19 kHz, +/- 3dB
Trennfrequenz (passiv): 2 kHz; 12 dB / Oktave
Schutzschaltung für Hochtöner:
Dynamische Schutzschaltung
Gewichte und Maße:
Gewicht: 17 kg / 37.4 lbs.
Maße (BxHxT):
35,5 cm x 52 cm x 38 cm • 14" x 20 1/2" x 15 "
Allgemeine elektrische Daten:
Schutzklasse 1 / protection class 1
(protectively earthed)
Max. Stromaufnahme:
8,6 A (230 V) • 17 A (117 V) • 20 A (100 V)
Max. Leistungsaufnahme: 2000 VA
Netzspannungsbereich: +/- 10%
Umgebungstemperaturbereich: -10° C bis +60° C
Interne Sicherung: 8 A
9 Technical Specifications
L.U.C.A.S 2000 Subwoofer
Inputs / Outputs:
Line In: XLR female (pin 1= ground; 2= +, 3= -) or
TRS (Sleeve = ground, Tip = +, Ring = -)
Input: Electronically balanced & floating
Input impedance: 47 k ohms
Sensitivity: 0 dBV (=1V) (Gain knob turned all the
way up)
Max. input level: + 14 dB
Parallel Out: XLR male (pin 1 = ground; 2 = +, 3 = -)
Speaker outs: Speakon
®
NL 4 (pin 1+ = +, pin 1- = -)
Amplifiers:
Subwoofer power output: 1200 W RMS
Satellite power output: 2x 400 W RMS
Protection circuits: Subsonic filter, Multi-band limiter
Active crossover: Crossover frequency: 110 Hz
Loudspeakers: Woofer: 1x 18"
Subwoofer frequency response:
40 Hz -110 Hz, ± 3 dB
Sound pressure level 1W / 1m: 103 dB (half space)
Max. sound pressure level / 1m: 131 dB @ 10% THD
(half space)
Weights and dimensions:
Weight: 56 kg / 123.2 lbs.
Dimensions incl. casters (WxHxD):
52 cm x 63 cm x 73 cm • 20 1/2" x 24 7/8 " x 28 3/4"
L.U.C.A.S 2000 Satellite
Inputs:
Speaker input: Speakon NL 4 (pin 1+ = +, pin 1- = -)
Loudspeakers:
Woofer: 1x 12" HK Audio Custom
Driver: 1x 1" B&C
Directivity: 60°x 40° CD Horn
Overall nominal impedance: 8 ohms
Nominal power handling capacity: 400 W RMS
Sound pressure level 1W / 1m: 105 dB (half space)
Max. sound pressure level / 1m: 126 dB @ 10% THD
(half space)
Frequency response (via active crossover):
110 Hz - 19 kHz, +/- 3dB
Crossover frequency (passive): 2 kHz; 12 dB / octave
Tweeter protection: Dynamic protection circuit
Weights and dimensions:
Weight: 17 kg / 37.4 lbs.
Dimensions (WxHxD):
35.5 cm x 52 cm x 38 cm • 14" x 20 1/2" x 15"
General electrical data:
Protection Class 1 (protectively earthed)
Max. current consumption:
8.6 A (230 V) • 17 A (117 V) • 20 A (100 V)
Max. power consumption: 2000 VA
Mains voltage range: +/- 10%
Ambient temperature range: -10° C to +60° C
Internal fuses: 8 A
Lucas2000_BDA_1.1 23.04.2004 17:21 Uhr Seite 28
