HK Audio l.u.c.a.s alpha Service Documents

66606 St. Wendel / Germany
HK0206-EX-R01-1A-TOP-GESAMT
HK0206-LUCAS ALPHA TOP
EXPLODED DRAWING COMPLETE
HK0206-EX-R01-1A
C.LORIS 2
Fehler: Keine Referenz
27.08.2007
A1
TITLE:
DRAWN BY:
PAGE:
DATE:
DRAWING-NO.:
VERSION:
REVISION:
CHECKED BY:
DATE:
MATERIAL:
FINISH:
FILENAME:
PAGES
INDEX CHANGES
RESP.
2
pos. no. part-no. 1 part-no. 2 description Beschreibung quantity
1 340143 front grille assembly Lucas Alpha satellite Frontgitterbaugruppe Lucas Alpha Top 1
2 400285 40 wooden cabinet Lucas Alpha sat 40 Holzgehäuse Lucas Alpha Top 1
3 520127 52 Crossover Lucas Alpha 52 Frequenzweiche Lucas Alpha 1
4 972008 damping wool Dämmwolle Hochbauschvlies 1
5* 972032 eggbox foam anthracite Noppenschaumstoff anthrazit 1
6 974017 hexagon socket countersunk head screw, M6x25, black Inbussenkschraube M6x25 sw 6
7 974020 hexagon socket head cap screw, M5x20, black Inbusschraube M5x20sw 6
8 974031 metal studs, unplated, M6x20 Stiftschraube, M6*20 blank 4
9 974108 plastic PCB spacer, 6.2x10x15, Polyamid black Dist.Hülse PE 6,2*10*15 [mm] 2
10 974127 toothed lock washer, D=6.4, AZ, zinc plated Fächer-Scheibe az, 6,4 vz 4
11 974216 hexagon socket countersunk head screw, M5x25, black Inbussenkschraube M5x25 sw 4
12 974227 hexagon nut, class 8, M6, zinc plated Sechskantmutter M6 vz 4
13 974233 washer, form A, D=6.4mm, zinc plated Unterleg-Scheibe 6,4 vz 6
14 974258 hexagon socket head cap screw, M5x40, black Inbusschraube M5 x 40 sw 2
15 974314 ABC-Spax-S screws for backwall, 4x40, black Rückwandschraube, 4*40 sw 1
16 974455 ABC-Spax-S chipboard screw, panhead Z, 5x16, black Pan Head-Z ABC-Spax sw 5*16 4
17 974466 ABC-Spax-S screws for backwall, 4x15, black Rückwandschraube, 4*15 sw 1
18 974499 hexagon socket countersunk head screw, M8x20, black Inbussenkschraube M8x20 sw 4
19 976001 rubber foot square, self-adhesive, black Gummifuss quadr. selbstkleb. sw 2
20 976009 rubber foot D38*H11 [mm] Gummifuss D38*H11 [mm] 4
21 976159 plastic dish Premium One Griffinnenschale Premium One 2
22 976174 flange for speaker stand, plastic, DuoTilt MKII Ständerflansch zweifach MKII, Kunststoff, schwarz 1
23* 982037 sealing tape 2x6mm Iso-Zell-Band fadenvers. 2*6mm 3,50 lfdm
24* 982044 sealing tape 2x15mm Iso-Zell-Band fadenvers. 2*15mm 1,04 lfdm
25* 986015 foam glue, Jowatac Schaumstoffklebstoff Jowatac xxx
26* 988208 Polyurethan Sabaflex 500 Polyurethan Sabaflex 500 xxx
27 994178 B&C DE250-14-8, 1.4" HF compression driver B&C DE254 8Ohm 1
28 994245 SICA LP320.75/N360T-8Ohms 12" SICA LP320.75/N360T-8Ohms 12" 1
29 994247 Horn 10HR 60°x40° 1,4" Horn 10HR 60°x40° 1,4" 1
