HK Audio l.u.c.a.s alpha Service Documents

66606 St. Wendel / Germany
HK0206-EX-R02-1A-TOP-FRONT
HK0206-LUCAS ALPHA TOP
EXPLODED DRAWING FRONT GRILLE
HU0206-EX-R02-1A
C. LORIS 1
Fehler: Keine Referenz
27.08.2007
A1
TITLE:
DRAWN BY:
PAGE:
DATE:
DRAWING-NO.:
VERSION:
REVISION:
CHECKED BY:
DATE:
MATERIAL:
FINISH:
FILENAME:
PAGES
INDEX CHANGES
RESP.
1
3 E 974158
4E 980124
1 E 970335
2E 972085
pos. no. part-no. 1 description Beschreibung quantity
1 970335 sheet metal Lucas Alpha sat front
grille stretched metal
Blech Lucas Alpha Top Streckgitter 1
2 972085 acoustic grille foam, black 15mm Akustikschaum Anthrazit, 15mm 1
3 974158 snapon retaining ring (for logo) Schnellbefestiger f. Logo 1
4 980124 logo ´HK´35*35 Logo ´HK´35*35 1
Fehler: Keine Referenz
Fehler: Keine Referenz
SERVICE-NO.: E340143
