HKS VFD Drive A2 Series User Manual

A2 VFD (0.75-30kW)
7
R
Basic Wiring (three phase)
three-phaseinput
FWD/STOP
REV/STOP
R
S
T
RUN
REV
P B
U
V IM
0.1u F
12 V
W
41 48 5k 1
D
DG
RESET
Multi speed D0 /
Digital freq uency up
Multi speed D1 /
Digital freq uency do wn
Multi speed D2 /
External point moving enable
RST
D0/+
D1/-
D2/JOG
5k 1
Normally closed Lb
Normally
closed output
Normally open Lk
Normally
open output
Common control signal
Theexternal analog signalgiven
0-5V,0-10V,0-20mA
GND
5V_IN
10 V_ IN
0-20 mA_IN
GND
5V_OUT
Middle Lz
5VFout
GND
12V
OUT
Common port
5VFrequency
signal output
200mAPower
output
external
po tentio meter
2
1-5K
5V_IN
GND
5V
OUT
Forexternal
potentiometerpower
main-loop port
control-loop port
Relay output
3
1
Port name
Description
R S T
Single phase 220V power connect R and T.
Three phase 220V power connect R , S , T .
Voltage specifications: 8xxx, single phase 220 input
connection R and T
U V W
Three phase AC output ports can only connect to pure
resistance or inductance load such as motors or electric
heater.
