HMS BE4200 - Page 10

9
3
Left support tube
1
A3
Hex screw M6*16
4
4
Right support tube
1
A4
Hex screw M8*16
4
5
Left end cap frame
1
A5
Hex screw M8*40
2
6
Right end cap frame
1
A6
Hex screw M10*35
2
7
Handlebar support frame
1
A7
Hex screw M8*60
2
8
Rear roller
1
A8
Hex screw M8*45
1
9
Front roller
1
A9
Hex screw M8*35
16
10
Motor
1
A10
Hex screw M8*75
2
11
Running deck support base
2
A11
Cross head self-lock bolt ST4.2*12
2
12
Eyebolt(Adjustable pole)
2
A12
Cross head self-lock bolt ST4.2*16
14
13
Computer
1
A13
Cross head half round bolt ST4*16
4
14
Running deck
1
A14
Cross head half round self-lock bolt ST4.2*10
10
15
Running belt
1
A15
Cross head self-lock bolt ST5*20
8
16
6v belt
1
A16
Cross blot M4*12
2
17
Wheel
2
A17
Cross head self-lock bolt ST4*16
2
18
Cushion
4
A18
Cross head self-lock bolt ST2.9*12
2
19
Finger-shape sensor permanent seat
1
B1
Nut M6
2
20
Motor base
1
B2
Nylon nut M8
15
21
Skid-proof fabric
2
B3
Nut M8
4
22
Upper motor cover
1
B4
stopping washer
2
23
Base motor cover
1
24
Left rear end cap
1
C1
Flat washer Ф4
12
25
Right rear end cap
1
C2
Flat washer Ф6
6
26
Handlebar (cover)
2
C3
Flat washer Ф8
8
27
Ф50 tube plug
2
C4
Flat washer Ф10
2
28
Locker
1
C5
Big flat washer Ф8
4
29
Adjustable foot pad
2
C6
Big flat washer Ф4
4
30
Wire (power / control wire)
1
C7
Spring washer Ф4
6
31
Transformer
1
C8
Spring washer Ф8
12
32
Driver(PCB)
1
C9
Arc washer Ф8
4
33
Safety key
1
34
Power plug
1
D1
Wrench
1
35
J50*25 square plug
2
D2
Screwdriver
1
36
Lock nut
2
D3
Lubricant bottle
1
37
Stator
4
D4
Wrench (s=6/ s=5)
1
