3
SU27
Some preparations before your first flight. Work time: 3-5 mins
1. Power on the transmitter and install the flight battery into the slot in the fuselage as shown.
(If the battery cannot be fixed properly, please use extra foam sheets to secure it in place.)
2. Switch the gyro mode to the gyro off position.
3. Ensure the control surfaces trim settings are all in the neutral position.
4. Then install elevons directly to the servo output rods. The elevons are pre-glued to the
servo horns and they should be installed with the screws supplied in the kit. (make sure
the elevons are level). Once that is done glue the fins as shown in the picture below.
5. Operate the control sticks on your transmitter and check that the control surfaces react
correctly to the stick commands.
