Super Cub S
Assembly continued
Wing Installation
Tail Installation
Clevis
Control
Horn
Clevis
Control
Horn
Rudder Control Linkage Install
Elevator Control Linkage Install
Clevis adjustment
x4
Bag B
x2
Bag B
x2
Bag C
IMPORTANT: The rubber bands prevent wing damage
from impact. Always replace worn or broken
rubber bands.
Gently fl ex
