Hobie Cat® Europe
Assembly manual - Hobie 15 CLUB
1. Insert the front trampoline lacing stripe into the cut out
in the track of the front crossbar. Position centrally.
2. Left and right halves of the trampoline
Stay outside the boat, behind the rear crossbar to assemble the two halves of the trampoline. Take the right half of the
trampoline, pout it on the reverse side and insert in the cut-out in the middle of the crossbar and pull it all the way to
the deck edge on the right. Lead the trampoline under the crossbar, the insert it in the cut-out of the side bar, all the
way to the front. Do the same thing for the left half of the trampoline. Firmly tension in order to lace correctly the tram-
poline halves.
Now the trampoline is ready for lacing.
TRAMPOLINE ASSEMBLY
