Hobie Mirage Compass Instructions

7
hobie.com
Seating
4
Make sure the seat clips are
attached to the boat... NOT the
retention loops on the seat itself.
Clip the two back straps to the pad
eye loops on each side of the cock-
pit. Adjust the strap lengths so that
the seat is in a comfortable upright
position.
Using the Seat Outside the Boat
2
Clip the two seat back straps to
the seat retention loops on the
sides of the seat frame. Adjust the
strap length so that the seat is in
a comfortable upright position.
1
Unclip the seat back hooks and frame
Bungees to detach the seat from the
boat.

Hobie Mirage Compass Specifications

General

Fitted Hull Weight	68 lbs / 31 kg
Capacity	400 lbs / 181 kg
Hull Construction	Rotomolded Polyethylene
Seat	Vantage CT
Length	12 ft / 3.66 m
Width	34 in / 0.86 m
Storage	Front Hatch, Rear Cargo Area
Vantage Seat Capacity	275 lbs / 125 kg
