Hobie Mirage Tandem Island User Manual

Assembly Required | 9
hobiecat.com
Rotate the mast counterclockwise so that the sail rolls onto the mast per the
diagram below.
7
Slide the batten cap over the ends of the battens and lace the line through the
cap. Make sure to pull tension on the line and cleat it off to hold on the cap and
retain batten pressure into the pocket. Tie off the end of the line for extra batten
security.
6
Feed the battens into the
batten pockets (note they
are different lengths per the
different length pockets)
5
1. PULL
2. CLEAT

Hobie Mirage Tandem Island Specifications

General

Length	18' 6" / 5.64 m
Capacity	600 lbs / 272 kg
Hull Construction	Rotomolded Polyethylene
Seating Capacity	2
Sail Area	90 sq ft / 8.4 sq m
Weight	240 lbs / 109 kg
