10 | Assembly Required
Rudder Installation
Place rudder over rudder
gudgeon and insert pin
1
Place the ring through
the hole in the end of the
rudder pin
2
Lift rudder up/down control
lines and make sure they
are running through the
middle of the rudder pin.
6
