Hobie Quest 13 - Lowrance Thru-Hull Plugs; Plug Preparation; Installing Wire Plug; Securing Thru-Hull Assembly

16
Locate the thru-hull
plug and unscrew the
nut on the inside of
the boat.
Gasket
Gasket
Remove the solid
rubber plug.
Choose the correct
plug for your wire
size and insert the
wire by opening the
plug along the slit.
Press the new plug
with the wire
installed into the
plastic plug making
sure it fits tightly.
DO NOT USE A
DRILL for the three
way plug. Bolt or
screw the thru-hull
wire assembly to the
hull using the nut or
screws. Make sure
you have the o-ring
or gasket installed.
O-ring
Thru-Hull Plugs, Single and 3-way
Lowrance Ready Option
1
2
3
4
5
