15
hobie.com
1/8”
3mm
The transducer is an optional
accessory and is not included with boat
Metal clips
ONLY ON QUEST 13
MODELS.
Lowrance Ready Option
Transducer Installation
Wire Installation
1.
2.
1.
There are plugs for the wire to
come out on either side of the
boat if you prefer a right/left
side screen location.
Run the cable into the plug
just behind the transducer
scupper.
Lead the cable through
the inside of the boat
and exit the cable out
through the thru-hull
fitting.
1
2
To Next Page
