Hobie Quest 13 - Vantage CT Seat Installation

8
Line up the
front of the seat
bottom frame
over key and
slide the back of
the frame to the
back wall in the
cockpit.
Put pressure
on the front of
the seat mesh &
lift the back of
the seat bottom
frame to set the
seat into the key.
Push the
seatback frame
down once the
seat frame is fit
into the key. Pull
up on front of
seat to check
for proper
installation.
Flip seat back
up.
Vantage CT
Seat Installation
1
2
3
4
