5. Capacity F
Function Range Resolution Accuracy Max.
Capacity
40nF 10pF
±(4.0%+5d) 400uF
400nF 100pF
4uF 1nF
40uF 10nF
400uF 100nF
6. . Frequency Hz
Function Range Resolution Accuracy Max.
Frequency
4kHz 1Hz
±(1.5%+8d)
4MHz
40kH 10Hz
400kH 100Hz
4MHz 1kHz ±(1.5%+40d)
7. Temperature
Function Range Resolution Accuracy Max.
Temperature
-40°C~400°C 1°C
±(1%+8d)
±(1.5%+15d)
1000°C
-400°C ~1000°C 1°C
6. MAINTENANCE
6-1. Battery replacement
If the symbol
appears on the LCD while using the meter, replace the battery to prevent incorrect reading of measurements.
1. Disconnect the test wires. Turn off the power.
2. Use a screwdriver to open the battery cover on the back, and then remove the battery.
3. Place the charged 9V 6F22 battery and replace the cover.
6.2. Fuse replacement
1. First remove the test lines and turn off the meter.
2. Use a screwdriver to open the rear cover, then remove the faulty fuse.
3. Insert a similar fuse, move the rear cover and fix it with screws.
6.3. Maintenance
If necessary, use a soft cloth to wipe the surface of the meter. Do not use organic solvents or abrasive materials that may corrode or
dissolve the case.
