Sampling frequency 3/s Contactless measurement √
Low battery indication: √ Auto off √
5.2. ELECTRICAL SPECIFICATION
1. CONTINUITY AND INDUCTIVE TEST
Continuity test √
NCV √
2. U DC/AC voltage
Function Range Resolution Accuracy Max.
UDC voltage
(V)
400mV 100uV
±(0.5%+5d)
2000V
4V 1mV
40V 10mV
±(0.8%+5d)
400V 100mV
2000V 1V (2.0%+5d)
UAC voltage
(V)
400mV 100uV
±(0,5%+5d)
2000V
4V 1mV
40V 10mV
±(0,8%+5d)
400V 100mV
2000V 1V (2.0%+5d)
3. Voltage I DC/AC
Function Range Resolution Accuracy Max.
IDC intensity
[A]
4mA 1uA
± (1.0%+3d)
± (1.0%+3d)
400mA40mA 10uA
400mA 100uA ± (1.0%+3d)
IUC voltage
[A]
4mA 1uA
±(2.0%+3d)
±(2.0%+3d)
400mA40mA 10uA
400mA 100uA ±(2.0%+5d)
4. Resistance R
Function Range Resolution Accuracy Max.
Resistance
400Ω 0.1Ω
±(1.0%+5d)
400MΩ
4KΩ 1Ω
40KΩ 10Ω
±(1.0%+5d)400KΩ 100Ω
4MΩ 1KΩ
40MΩ 10KΩ ±(1.2%+8d)
400MΩ 100KΩ ±(4%+10d)
