ATTACHING A TANK
The HD200 is only designed to handle a single tank and uses a single cam band against a contoured hard
plastic backplate that holds the tank securely (Fig. 14). Use the attached adjustable guide strap to position the
tank on the contoured backplate by placing it around the neck of the tank (Fig. 15).
Fig. 14 Fig. 15
Use the following steps to weave the cam band. Nylon may loosen when wet, to ensure an extra secure hold,
soak the straps in water before tightening:
• Pull the band through SS (Stainless Steel) attachment at the base of the buckle (Labeled 1) so the band is
now on the outside of the buckle (Fig. 16).
• Now weave the band through the middle slot (Labeled 2) from outside to inside (Fig. 17).
• Now weave the band through the bottom slot (Labeled 3) of the buckle so the band is against the tank (Fig.
18, 19).
Fig. 16 Fig. 17
