PAGE 5
Programming Example (cont.)
Example: 8 Station Controller
FREQUENCY OF
WATERING
PROGRAM
NO
STATION WATERING
DURATION
WATERING
START TIME(S)
1 1 1 2 2 2 1 2
20 Mins 20 Mins 20 Mins 30 Mins 10 Mins 10 Mins 20 Mins 5 Mins
4.00AM 6.00AM 6.00AM 4.00AM 6.00AM
Mon, Wed, Fri Every Day Every Day Mon, Wed, Fri Every Day
GARDEN AREASTN. NO
1 2 3 4 5 6 7 8
Front Lawn Front Lawn Front Lawn Vegetables Flower Bed Flower Bed Back Lawn Pergola
Programming Instructions
Other Functions
This controller can also manually run a selected program
once, or an individual station can be set to run once from
1 minute up to 12 hours and 59 minutes. During winter
the automatic schedules can be suspended to prevent
watering while it is raining. A test facility for checking the
valves and sprinklers is also provided.
General tips for easy programming
Tips to help eliminate programming confusion.
l Complete the spare watering planner.
l When setting, one push of the button will increment
one unit.
l Holding one button down will fast scroll through units.
l During programming, flashing units are able to be set,
using
or buttons
l Pressing
next
will scroll forward through the settings
in an orderly sequence.
l Pressing
back
will scroll back to previous settings and
settings can be changed.
Programming Example
A typical example of a 8 station system is included on the
following page as a guide to assist you when planning
your watering schedule.
In this example, the lawn areas are using pop-ups and
require less frequent watering.
The vegetables are being watered using drippers, and
the flower beds and pergola areas are being watered
with micro sprays.
PAGE 4
