CLEANING/MAINTENANCE INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan.
REPLACEABLE FUSE
If the (2.5 Amp, 125 Volt)
replaceable fuse blows, please
contact customer service for
information on how to order a
new fuse. Follow the below
instructions to replace the fuse
on the plug.
User Servicing
Instructions
1. Unplug fan. Grasp plug and remove from the
receptacle or other outlet device. Do not unplug by
pulling on cord.
2. Open fuse cover, located on the top of the plug, by
using your thumb or a flathead screwdriver to slide
the cover down towards the prongs.
NOTE: Ensure that fuse cover is completely open
before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver
to pry the fuse out of the compartment by the metal
ends of the fuse. (see Figure 4)
4. Place plug on a solid, flat surface. Insert new
2.5 Amp, 125 Volt fuse into fuse compartment and
use a small screwdriver to secure the metal ends of
the fuse into the compartment.
CAUTION: Risk of fire. Replace fuse only with
2.5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely. If fuse cover is
difficult to close, make sure fuse is secured in place
completely by pressing down on metal ends of the
fuse.
6. Risk of fire. Do not replace attachment plug.
Contains a safety device (fuse) that should not be
removed. Discard product if the attachment plug is
damaged.
FAN CLEANING
1. Always unplug the fan before cleaning.
2. Do not allow water to drip on or enter into fan
housing.
3. Be sure to use a soft cloth moistened with a mild
soap solution.
4. Do not use gasoline, thinner or benzene as a cleaner.
Clean the fan grill, housing and base with a soft, damp
cloth. Do not attempt to remove the fan blade. Use
CAUTION around the motor housing area. Do not allow
the motor or other electrical components to be exposed
to water.
FAN STORAGE
• Store the fan in a clean, dry location between
seasons or when not in use for an extended period.
• Keep the fan protected from dirt and dust during
storage.
NOTE: This fan can also be used during the cold winter
season to circulate warm air throughout your home.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS
FEATURES - OPERATIONS
FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual. This fan is not for continuous operation or
equivalent.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids and
plug the appliance directly into a 120V AC electrical
outlet.
4. Not intended for use by children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
return to an authorized service facility for
examination and/or repair.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
11. WARNING: To reduce the risk of fire, electric
shock, or injury to persons, do not use replacement
parts or attachments not recommended by the
manufacturer (e.g. parts made at home using a 3D
printer).
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all
parts properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock
and injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This fan employs overload protection (fuse). A blown
fuse indicates an overload or short-circuit situation. If
the fuse blows, unplug the product from the outlet.
Replace the fuse as per the user servicing instructions
(follow product marking for proper fuse rating) and
check the product. If the replacement fuse blows, a
short circuit may be present and the product should
be discarded or contact customer service.
ASSEMBLY INSTRUCTIONS (SEE FIGURE 1 & 2)
Estimated assembly time: 5-10 minutes, tool-free.
NOTE: MAKE SURE TO REMOVE ALL CONTENTS FROM THE
PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO OPERATE YOUR FAN.
1. Assemble Base Halves (E) around power cord. Refer
to Figure 2, Step 1.
2. To secure the base halves together, slide the posts of
one base half into the slots of the second base half.
Refer to Figure 2, Step 2.
3. Line up the Base Locking Holes (G) with the Locking
Posts (F) on the bottom of the Fan Housing (D).
Refer to Figure 2, Step 3.
4. Secure by turning the base clockwise around the
Locking Posts until an audible click is heard. Refer to
Figure 2, Step 3.
5. Turn fan right side up and place on a dry and level
surface.
OPERATING INSTRUCTIONS (SEE FIGURE 3)
1. Plug the cord into a standard 120V AC outlet.
2. To turn the fan ON, rotate the Speed Control Knob
(H) clockwise to the desired speed.
1 - Low
2 - Med
3 - High
3. To turn on with oscillation, rotate the Oscillation
Control Knob (I) counterclockwise to the desired
speed.
1 - Low
2 - Med
3 - High
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
A
B
D
C
E
A. Control Dial
B. Fan Housing
C. Power Cord
D. Fan Grill
E. Base Halves
Figure 1
Figure 2
H. Speed Control Dial
I. Oscillation/Speed Control Dial
F. Locking Posts
G. Locking Holes
G.
F.
Figure 3
I
H
Figure 4
Fuse
Metal ends
Fuse cover
For inquiries regarding recycling and proper disposal
of this product, please contact your local waste
management facility.
CLEANING AND MAINTENANCE
ASSEMBLY INSTRUCTIONS
Step 1
Step 2
Step 3
