Page #8 background imageLoading...
Page #8 background image
7
SPECIFICATIONS
DIGITAL OUTPUTS
COAX-1, COAX-2, OPT, AES-EBU
PCM 44.1-192KHz (24 bit)
DSD 64X (DoP)
I2S (HDMI)
PCM 44.1-768KHz (24 bit)
DSD 64-512X (Native), 641256 (DoP)
CHASSIS SPECIFICATIONS
Size
212x143x42mm(WxLxH)
net weight
2.4kg
POWER SPECIFICATIONS
Power input*
220~230V 50/60Hz - T1A (5x20mm)
*Configurable, see the bottom label
of the machine for details
100~115V 50/60Hz -T2A (5x20mm)
Power consumption
15W
ACCESSORY
TF Card
Micro SD Card x1*
*Pre-installed with custom bridge
system
FUNCTIONS & CONFIGURATION
FRONT PANEL
LED status indicator: the power indicator is green and steady, and the load indicator
is red and flashing (it is normal to flash or turn off according to the load used)
