HOLZTECH SD-320 – 240V - Wiring Lay-out

Holztech SD320
WWW.HOLZTECH.COM
Functions of under voltage triggers
At voltage drop in the factory the main switch goes off and the machine has to be switched on
again.
Electronic motor brake
Maximum run time of the motor is 1 0 seconds after switching-off the motor. In case this time
gets longer an electdeian has to be consulted.
11.3 Motor
Type: AC
Design: B3
P'rotection: IP 54
Rotation: 3000 r/min. at 50Hz
Power: 2.0 kVA
Current: 240V/50Hz
Heat protection: B
Insulation class F
11.4 Wiring lay-out
