Structure and parts
1. Front grill
2. Blade fasten nut
3. Blade
4. Grill fasten nut
5. Back grill
6. Dam-board
7. Motor cover
8. Back control box
9. Control panel
10. Bolt
11. Power cable
12. Adjustable tube
13. Fixing tube clamp
14. Tube
15. Base
16. Gasket
17. L shape screw
Assembly Instructions
The fan is packaged with its grills un-attached. You must attach the grills
before operating the fan.
WARNING: Never operate the fan without its foundation and other
parts. The fan must only operate in the up-right position, and any
other position will be hazardous.
Do operate the fan only in upright position; any other position could create
a hazardous situation.
