ASSEMBLY INSTRUCTIONS
NOTICE!
Before assembly:
a) Please ensure you have enough space around the machine.
b) Please use the provided tools.
c) Check the parts and the hardware first.
STEP 1
Remove and unpack the Main frame (1) from
the carton, unfolding it and aligning the inner
adjust tube(25). Screw together with the ball pin
(24) to secure.
STEP 2
Connect the Front (2) and Rear (3) bottom tube to the
Main Frame (1) with 4 x M8*62 nuts (6), 4 x M8 Curved
washer (5) and 4 x M8 x 62 screws (4).
