Parts List No.1 :
No. Description QTY No. Description QTY
1 Rear Stabilizer 1 39 Foam Grip 2
2 Rear End Cap 2 40 Screw M8*60 2
3 Screw M10*57 4 41 Screw M8*20 3
4 Front Stabilizer 1 42 Front Post 1
5 Front End Cap 2 43 Bushing 2
6 Washer D10 4 44 Washer φ19 2
7 Nut M10 4 45 Monitor 1
8 Screwφ16×89×1/2"×20-L 1 46 Screw M5*10 2
9 Washer φ16 2 47 Hand Pulse 2
10 Bushing φ28 4 48 Washer φ6*φ12*1 2
11 Washer φ13 2 49 Screw ST4.2*20 2
12 Nylon Nut 1/2"×20- L 1 50 Middle Handle Bar 1
13 Cap S18 2 51 Foam Grip 2
14 Screw φ16×89×1/2"×20-R 1 52 Plug 2
15L Pedal Tube-L 1 53 Middle Wire 1
15R Pedal Tube-R 1 54 Tension Control 1
16 Nylon Nut 1/2"×20-R 1 55 Screw M5*40 1
17 Pedal 2 56 Washer D5 1
18 Screw M10×45 7 57 Plug 2
19 Washer φ10.5*φ20*2 4 58 Crank 1
20 Nylon Nut M10 6 59 Main Frame 1
21 U Shape Seat 2 60 Sensor Wire 1
22 Wash φ10.5*φ26*2 4 61 Wrench S6 1
23 Nylon Nut M8 4 62 Wrench S8 1
24 Cap S13 6 63 Wrench S13-14-15 1
25 Bushing 2 64 Wrench 17-19 2
26 Bushing φ32 4 65 Washer φ8.5*φ16*1.5 5
27 Screw M8×65 2 66 Plastic Cover 1
28L Coupler Bar-L 1 67 Screw ST4.2*20 7
28R Coupler Bar-R 1 68 Wire Plug Φ12 2
29 Screw M8*16 2 69 Screw M8*30 2
30 Washer D8 7 70 Seat Cushion 1
31 Washer φ8.5*φ32*2 2 71 Bushing 1
32 Bushing φ32 4 72 Adjust Tube 1
33 Screw M8*35 2 73 Seat Tube 1
34 Washer D8 9 74 Knob 1
35 Nut M8 2 75 Knob 1
36 Cushion 2 76 Plug 2
37L Handle Bar-L 1 77 Nut M8 3
37R Handle Bar-R 1 78 Washer φ8.5*φ19*1.5 3
38 Cap φ28 2 79 Cushion 1
To Next Page
