HOMCOM A91-176 - Step 3; Step 4

ASSEMBLY STEPS
STEP 3:
Attach the Support Frame (8) to the Front Base
Frame (20) using 2 Hex Bolts (58), 4 Washers (67)
and 2 Nylon Nuts (70).
Attach the 2 Single Pulley Blocks (21) to the Support
Frame (8) using 2 Hex Bolts (58), 4 Washers (67)
and 2 Nylon Nuts (70).
Do not overtighten the Single Pulley Blocks (21).
They must be secure, but must still be able to move.
STEP 4:
Attach the Front Support Frame (4) to the Front
Base Frame (2) with 1 Hex Bolt M10 x 60 mm (58),
2 Washers (67) and 1 Nylon Nut (70).
Now attach the Seat Base Frame (7) to the Front
Support Frame (4) and the Front Base Frame (2).
Ensure all bolts are tight before proceeding.
8
58
67
67
70
57
67
67
21
70
Step3
STEP 3
STEP 4
2
58
58
67
67
67
67
67
67
67
70
70
70
4
7
58
58
8
Step4
34
