Attach the Dash & Steering Wheel │ 7
3. With a screwdriver loosen the
screw on the battery cover located
in the center of the steering wheel.
4. Remove the battery cover from the
top of the battery compartment.
5. Insert 2x1.5 AA batteries in their
correct polarities.
6. Place the battery cover over the
battery compartment and fasten
with the screw you loosened in
step one.
Please follow the steps 1-4 to add the batteries (Not Included), and refer to the battery
information on page 2.
1. Plug the light unit connector on the dash into light connector on the vehicle body. Hide
the pluged connectors into the hole in the vehicle body.
2. Fit the tabs on the dash into the holes in the vehicle body, and push until you hear it
“click” into place.
To Next Page
