Attach the Steering Wheel, Windshield & Side Mirrors │ 8
Remove the M5x35 machine screw and Ø5 nut from the steering wheel.
Turn the vehicle body upright.
1. Place the steering wheel over the the steering column, protruding from the middle of
the steering wheel base.
Attach the Steering Wheel
2. Align the holes on each side of steering
wheel with the holes at the end of the
steering column.
3. Fasten a nut on the opposite end of the
screw to secure the steering wheel to
the steering column.
End of steering column
4. Fit the tabs windshield into the grooves on the vehicle. Press until you hear it “click”
into place.
5. Fit the side mirrors to the holes on the both doors, push until you hear them “click”
into place.
To Next Page
