UK - Page 13
CHAIN OIL SYSTEM
See Figure 9.
Use HOMELITE Bar and Chain Oil. It is designed for
chains and chain oilers, and is formulated to perform over a
wide temperature range with no dilution required. Chainsaw
should use approximately one tank of oil per tank of fuel.
NOTE: Do not use dirty, used or otherwise contaminated
oils. Damage may occur to the oil pump, bar or chain.
1. Carefully pour the bar and chain oil into the tank.
2. Fill the oil tank every time you refuel the engine.
STARTING THE ENGINE
See Figures 10 to 19.
WARNING:
Keep your body to the left of the chain line. Never
straddle the saw or chain, or lean over past the
chain line.
1. Place the chainsaw on level ground and ensure that no
objects or obstructions which could come in contact with
the bar and chain are in the immediate vicinity.
2. Hold the front handle firmly with the left hand and put
your right foot onto the base of the rear handle.
BRAKE POSITION
IGNITION SWITCH
IN THE RUN
POSITION
PRIMER BULB
Fig. 9
Fig. 13
Fig. 12
Fig. 11
Fig. 10
Fig. 8
OPERATION
