UK - Page 14
Fig. 14
FULL CHOKE
CHOKE LEVER
HALF CHOKE
RUN POSITION
Fig. 15
THROTTLE TRIGGER
THROTTLE
LOCK
BUTTON
TRIGGER
RELEASE
Fig. 16
Fig. 17
THROTTLE TRIGGER
TRIGGER
RELEASE
Fig. 18
RUN POSITION
STARTER
GRIP
STARTING A COLD ENGINE:
3. Move the chain brake to the BRAKE position.
NOTE: Set the chain brake by pushing the chain brake
lever/hand guard forward (towards the bar) to the brake
position. Refer to “Operation – Operating the Chain
Brake” later in this manual for additional information.
4. Set the ignition switch to the RUN (I) position.
5. Fully press and release the PRIMER BULB 7 times.
6. Pull CHOKE lever all the way OUT to full position.
7. Engage trigger release.
While squeezing both the trigger release and throttle
trigger, push in the throttle lock button. Release the
throttle trigger. This latches the trigger for starting.
OPERATION
