Homelite HBC26SB User Manual

SPECIFICATIONS
HBC26SB HBC30SBS
Weight
- Without fuel, cutting attachment and guard kg 5.45 6.79
- Without fuel with string head kg 5.65 6.96
- Without fuel with blade kg 5.49 6.96
Fuel tank volume cm
3
or (L) 300 or (0.3) 425 or (0.425)
Cutting swath
- String head mm 457 457
- Blade mm 200 200
Recommended torque for blade retention Nm >=11 >=13
Engine displacement cm
3
/ cc 26 30
Line diameter mm 2.4 2.4
Max engine performance
(in accordance with ISO 8893) kW 0.65 0.78
Maximum rotational frequency
of the the spindle min-
1
10,000 10,000
Engine speed (rotational frequency)
at recommended max. spindle
rotational frequency min-
1
12,000 12,000
Engine speed (rotational frequency)
at idle min-
1
3,200-3,800 2800~3500
Fuel consumption (in accordance
with ISO 8893) at max. engine performance kg/h or (L/h) 0.33 or (0.45) 0.48 or (0.66)
Specific fuel consumption
(in accordance with ISO 8893)
at max. engine performance g/kW.h or (L/kW.h) 508 or (0.7) 640 or (0.87)
Vibration level idling (Trimmer)
- Front handle / Left handle m/s
2
5.6 5.3
- Rear handle / Right handle m/s
2
7.8 4.3
Vibration level racing (Trimmer)
- Front handle / Left handle m/s
2
10.7 9.7
- Rear handle / Right handle m/s
2
15.5 16.5
Vibration level idling (Brush Cutter)
- Front handle / Left handle m/s
2
3.5 6.8
- Rear handle / Right handle m/s
2
6.2 4.4
Vibration level racing (Brush Cutter)
- Front handle / Left handle m/s
2
6.6 4.4
- Rear handle / Right handle m/s
2
12.5 14.1
Sound pressure level
(in accordance with EN 27917) dB (A) 100.5 104.3
Sound power level (in accordance
with ISO 10884) dB (A) 108 111
15
English
GB
F D E I P NL S DK N FIN GR HU CZ RU RO PL SLO HR TR EST LT LV SK BG
960720001-01.indd 15960720001-01.indd 15 12/6/07 5:37:00 PM12/6/07 5:37:00 PM

Homelite HBC26SB Specifications

General

Brand	Homelite
Model	HBC26SB
Category	Trimmer
Language	English
