5. Open the vacuum inlet door.
6. Align the raised locking tabs with the
matching orice on the upper vacuum
tube to secure the upper and lower
vacuum tubes together. An audible click
can be heard to indicate that the blower
tubes are secured.
7. Align tabs on housing with vacuum
tube assembly. Tighten screws on
upper vacuum tube to secure to blower
housing.
8. Start the blower. Refer to the “Starting a
cold engine” or “Starting a warm engine”
section for the procedure. Squeeze the
throttle trigger to start the vacuum.
NOTE: Place the vacuum bag strap
over your right shoulder. Hold the upper
handle in your left hand and the vacuum
handle in your right hand.
