Homelite HBL26BVB - Cleaning the Blower;Vac

32
2
1
1
3
1
2
3
1
2
A1
1
B1
B2
CLEANING THE BLOWER/VAC-
UUM
1. To stop the engine, toggle either the
blower or vacuum switch to the “STOP”
position.
A1.To remove the blower tube, twist and
remove the tube from the blower
housing outlet.
B1.To remove the vacuum tube assembly,
loosen the screws that secure the tube
assembly to the inlet cover.
B2.Press on the raised locking tab, and then
detach the upper vacuum tube from the
lower vacuum tube.
