Page 12
STOP
STOP
Fig. 11
FULL CHOKE
CHOKE LEVER
HALF CHOKE
RUN POSITION
Fig. 12
THROTTLE TRIGGER
THROTTLE
LOCK BUTTON
TRIGGER
RELEASE
Fig. 13
Fig. 14
THROTTLE TRIGGER
TRIGGER
RELEASE
STARTER
GRIP
STARTING THE ENGINE:
3. Set the ignition switch to the RUN (I) position.
4. Fully press and release the PRIMER BULB 7 times.
5. Pull CHOKE lever all the way OUT to full position.
6. While squeezing both the trigger release and throttle
trigger, push in the throttle lock button. Release the
throttle trigger. This latches the trigger for starting.
OPERATION
