Homelite UT10532 Replacement Parts List

3
HOMELITE UT10532 16 in. 33cc CHAIN SAW
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY
PARTS LIST
The model number will be found on a plate attached to the engine housing. Always mention the model
number in all correspondence regarding your CHAIN SAW or when ordering replacement parts.
Key Part
No. Number Description Qty.
1 671076001 Guide Bar Nut (5/16-18) ..................................................................................2
2 308006001 SAFE-T-TIP ......................................................................................................1
3 308625001 Guide Bar (16 in.) (Incl. Key Nos. 2 and 5) .......................................................1
4 308116002 Guide Bar Adjustment Assembly .....................................................................1
5 660640001 SAFE-T-TIP (Screw and Washer) .....................................................................
1
6 638173001 Outer Guide Plate ............................................................................................
1
7 660619001 * Screw (6-19 x 1/2 in. T.F.) .................................................................................2
8 660636001 * Screw (10-16 x 1-1/2 in. Special) .....................................................................3
9 518238001 Top Cover .........................................................................................................1
10 660617001 * Screw (8-16 x 16 mm Torx T.F.) ........................................................................2
11 518306001 Air Filter Cover .................................................................................................1
12 870170001 Spark Plug (Champion RCJ4) ..........................................................................1
13 660868001 * Screw (10-24 x 5/8 in. Torx Pan Hd.) ...............................................................1
14 518283001 Baffle ................................................................................................................1
15 308382001 Starter Cover Assembly ...................................................................................1
16 660632001 * Screw (10-14 x 5/8 in. Torx Pan Hd.) ...............................................................
6
17 308362001 Fuel Cap Assembly ..........................................................................................1
18 308363001 Oil Cap Assembly ............................................................................................1
19 660624001 * Screw (8-32 x 5/16 in.) .....................................................................................2
20 638148001 Plate .................................................................................................................1
21 638147001 Spark Screen ...................................................................................................1
22 300940005 Muffler Assembly (Incl. Key Nos. 19-21) ..........................................................
1
23 671079001 * Lock Nut (10-32) ..............................................................................................3
24 660765001 Bolt (Square Hd.) ..............................................................................................3
25 308369001 Combination Wrench .......................................................................................
1
26 900856002 Chain ................................................................................................................1
27 308364001 Chain Cover Assembly .....................................................................................1
28 900844002 Pre-Filter ..........................................................................................................1
29 638169001 Inner Guide Plate .............................................................................................1
30 671103001 E-Ring ..............................................................................................................1
31 631060001 Cupped Washer ...............................................................................................
1
32 300958001 Sprocket Drum & Bearing Assembly ...............................................................1
33 638176001 Bumper Spike ..................................................................................................
1
34 678744002 * Lock Nut (10-24) ..............................................................................................1
35 300759003 Fuel Filter .........................................................................................................1
36 631035001 Chain Guide .....................................................................................................1
37 120640001 Tool Holder Assembly ......................................................................................1
38 638041002 Deflector ...........................................................................................................1
39 900977003 Gasket ..............................................................................................................
1
40 638381001 Heat Shield .......................................................................................................1
580656001 Scabbard (Not Shown) .....................................................................................
1
983000735 Operator’s Manual (Not Shown) .......................................................................1
983000789 Replacement Parts List ....................................................................................1
