5
10
15
20
25
30
35
40
Key
No.
Part No.
Description Qty
Key
No.
Part
No.
Description Qty
1
8000-516910
battery assy 1
43
8001-517001
upper handle
1
2
8181-516902
right shutter 1
44 8206-517001
bolt 2
3
8181-516901
left shutter
1
45 8007-517001
cord guide 2
4
8020-516901
motor vent 1
46
8331-516201~1
grip
1
8SNAB30-10B
self-tapping screw 2
47
8000-516909
switch and power cable assy
1
6
8206-516001
cover
screw
6
48 8214-516401
key wire
1
7
8024-516901
motor
cover
1
49
8020-516905
side discharge deflector
1
8331-517003
cover
envelope
1
50 8020-516904
side discharge door
1
8413-510601
connection
wire
1
51
8025-516205 rubber cap
4
8416-516203
connection
wire
1
52
8342-516202~1
compression
spring
1
11
8024-516202
cap 4
53 8081-516204
side discharge pin 1
12
8NH~80
nut 4
54 8321-517008
side discharge bracket 1
13
8325-532405
washer 4
55 8SQOO06-0808.8
machine
screw
2
14 8121-516306
right wheel
2
56 8001-516402
holght adjustment handle
8224-516201
axle sleeve 4
57 8SKC005-14QI2.9
screw
4
16 8202-517201
adlusHng shim 12
58 8NG-05QOI8.8
flange bolt
12
17
8SACOOS-12Q8.8
hex socket head cap screw 4
59
8321-516901~1
spring pad
1
18
8NG-05QOI8.8
hex nut
B
60
8321-517002
height adjustment bracket right
1
19
8440-516901
front wheel axle
1
61
8336-517101 shock pad
1
8121-516305
front left wheel
2
62
8401-516901
motor
1
21
8NH-06Q8.8 self-locking nut
63 8SQOO06-1608.8
bott
3
22
8087·516901
link bar
64 8SJAB50-16Q self-tapping screw
3
23 8342-517002
extension
spring
65 8141-517002 wire clamp plate
1
24 8006-516902
deck
66 8184-282102 power cord clamp plate
1
8224-516202 spindle guard
67
8SJAB40-16Q self-tapping screw
22
26
8403-517001
fan
68 8SFOD06-1608.8
hex head screw
3
27
8231-516902
blade
69
8149-516201
wire
connector
1
28 8181-517002
blade Insulator
70 8WF-060 washer
6
29
8321-517006
spacer
71
8WS~60
spring pad
3
8207-517001
blade nut
72
8NA~6001
hex nut
3
31
8SBC010-20D8.8 hex head screw
4
73
8414-516201
LEO
1
32
8WS-
l0Q
spring pad 4
74 8024-516213
plug cap
1
33 8ND-l0DOI8.8
hex nut 4
75 8SJAB40-20Q
self-tapping
Gcrew
2
34 8321-517003
height adjustment bracket left 1
76
8413-516403
connection
wire
1
8SGN04-16QI2.9
screw
3
77
8141-516901
fixing seat
1
36
8NH-04Q8.8
self-locking nut 3
78
8426-516201~1
charger
1
37
8187-516201
rubber board
3
79
8007-516401
cord guide upper cover
1
38
8186-517002
chip 3
80 8336-516411
gasket
2
39
8181-516904
rear flap 1
81
8007-516402 cord guide lower cover
1
8440-516302
rear wheel 8xle assy 1
82 8SJAB40-14Q
self-tapping screw
1
41
8313-516301 knob
4
83 8SJAB30-15Q
self-tapping screw
1
