HOMELITE 26cc MIGHTYLITE STRING TRIMMER – MODEL NUMBERS UT21546 AND UT21947
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST (FIGURE B)
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 870174001 * Spark Plug (Champion RCJ6Y) .........................1
2 940734008 Starting Label ....................................................1
3 678029002 * Hex Nut (M6) ......................................................1
4 518496001 Choke Dial Cover ...............................................1
5 678434001 Flat Washer ........................................................1
6 678435001 * Hex Nut (M4) ......................................................1
7 678434002 Wavy Washer .....................................................1
8 308680001 Fuel Cap ............................................................1
9 660697002 * Bolt (M6 x 20 mm) .............................................1
10 270032001 Throttle Cable ....................................................1
11 518529001 Throttle Trigger ..................................................1
12 518674001 Handle ...............................................................1
13 678008001 * Flat Washer ........................................................1
14 678034001 Wing Nut (1/4-20) ..............................................1
15 660643008 * Bolt (1/4-20 x 40 mm) ........................................1
16 518949001 * Wing Nut (1/4-20) ..............................................1
17 678436001 Mounting Bracket ..............................................1
18 308781001 Straight Shaft Grass Deflector
(Inc. Key Nos. 14 and 17) ..................................1
19 308746002 Large String Head Housing ...............................1
20 308044007 Dual Line Spool and String ................................1
21 308042003 Spool Retainer ...................................................1
22 000998358 Boom Assembly ................................................1
23 940642020 Warning Label ....................................................1
24 678022001 Spring ................................................................1
25 120152001 String Head Assembly .......................................1
26 760700002 Switch ................................................................1
27 660634001 * Screw (8-16 x 5/16 in.) .......................................1
28 940642026 Logo Label .........................................................1
29 940647008 Choke Label ......................................................1
30 308741001 Handle Assembly
(Inc. Key Nos. 12, 13, 15, and 16) .....................1
31 678011002 Flange Washer ...................................................1
32 678019002 Shaft Adapter ....................................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
