HOMELITE 26cc MIGHTYLITE STRING TRIMMER –
MODEL NUMBERS UT21506, UT21546, UT21907, UT21947
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
1 308891001 Short Block Assembly (Inc. Key Nos. 32-34).....1
2 660968001 * Screw (M4 x 19 mm) ..........................................2
3 660967001 * Screw (M4 x 14 mm) ..........................................3
4 638389001 Pulley Retainer ...................................................3
5 308386001 Starter Pulley Assembly .....................................1
6 518502001 Pulley Handle .....................................................1
7 638033001 Spring & Container Assembly ............................1
8 308672001 Front Housing ....................................................1
9 660970001 * Screw (M4 x 16 mm) ..........................................4
10 308671001 Front Housing Assembly (Inc. Key Nos. 3-8;
Plus Key Nos. 10, 11 and 25 from pages 2 & 3) ...1
11 518504001 Rear Housing .....................................................1
12 660466001 * Screw (M4 x 8 mm) ............................................4
13 901551001 * Intake Gasket .....................................................1
14 518497001 Heat Dam ...........................................................1
15 518685001 Heat Dam Deflector ...........................................1
16 901552001 Carburetor Gasket .............................................1
17 308054001 Carburetor .........................................................1
18 518498001 Choke Base .......................................................1
19 660454001 * Screw (M5 x 70 mm) ..........................................1
20 660453001 Double Sided Hex Bolt ......................................1
21 850108002 Ignition Module ..................................................1
22 308863001 Lead Assembly ..................................................1
23 901452001 Muffler Gasket ...................................................1
24 308990016 Muffler Assembly ...............................................1
25 308675002 Fuel Tank Assembly w/Cap
(UT21506 & UT21546) .......................................1
308675001 Fuel Tank Assembly w/Cap
(UT21907 & UT21947) .......................................1
26 638442001 Heat Shield ........................................................1
27 660970002 * Screw (M4 x 10 mm Shoulder) ..........................3
28 308811001 Flywheel Assembly ............................................1
29 631049001 Washer ...............................................................1
30 638348001 Drive Connector .................................................1
31 660638003 * Screw (10-24 x 2-3/16 in.) .................................2
32 901550001 Gasket ...............................................................1
33 638337001 Crankcase Cover ...............................................1
34 660925003 * Screw (M4 x 12 mm) ..........................................6
35 900849002 Starter Rope (42 in. (Not Shown) .......................1
