HOMELITE PRESSURE WASHER — MODEL NOS. UT80522B/UT80953B
FIGURE A PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
The model number will be found on a label attached to the frame. Always mention the model number in all correspondence regarding your PRESSURE
WASHER or when ordering replacement parts.
1 309591067 Engine (UT80522B) ...................1
309591039 Engine (UT80953B) ...................1
2 678041007 Output Shaft Key
(3/16 x 40 mm) ..........................1
3 308418005 Pump .........................................1
4 308582026 Main Frame ...............................1
5 518790009 Nozzle Holder ............................1
6 561307003 Rubber Foot ..............................1
7 308638030 Handle Assembly
(Inc. Key No. 8) ..........................1
8 308421004 Lock Button w/Spring Clip ........2
9 308316005 Wand Holder (Upper) ................1
10 678016006 Lock Nut (1/4-20) .....................9
11 661557011 Bolt
(5/16-24 x 27 mm, Hex Hd.) ......4
12 638678001 Lock Washer (5/16 in.) ...............4
13 638675005 Washer (5/16 in.) .......................4
14 661503013 Screw (1/4-20 x 2.0 in., Torx) ....4
15 678169004 Thermal Release Valve ..............1
16 661503001 Bolt (1/4-20 x 1-1/4 in.) .............1
17 638128004 Washer (1/4 in.) .........................1
18 660764002 Bolt (M8 x 40 mm,
Hex Flange Hd.) ........................4
19 308835006 Hose ..........................................1
20 310801001 Hook and Loop Strap ................1
21 308760019 Trigger Handle ...........................1
22 308506006 Extension Wand ........................1
23 308451018 Wheel Assembly
(10 in. x 3 in.) .............................2
24 308697012 Nozzle, 0º ..................................1
25 308700012 Nozzle 40º .................................1
26 308699012 Nozzle 25º .................................1
27 308706011 Soap Nozzle ..............................1
28 620599019 Axle ...........................................2
29 678899001 Hitch Pin ....................................2
30 638275002 Washer (1/2 in.) .........................2
31 678243012 Wand Holder (Lower) .................1
32 678973001 Front Panel ................................1
33 678774001 Lock Nut (M8 x 1.25) .................4
34 308103015 Filter ..........................................1
35 561399003 Chemical Siphon Tube ..............1
36 940617095 Pump Start Label ......................1
37 940617102 Engine Start Label .....................1
38 940633005 Recoil Label ...............................1
39 940647080 Choke Label ..............................1
40 940678247 Data Label .................................1
41 940680027 Hot Surface Label .....................1
42 940786016 Trigger Handle Logo Label ........1
43 940748005 Homelite Label ..........................1
44 940779071 Performance Label ....................1
45 940871002 Add Oil Label .............................1
46 940894001 Danger Label .............................1
47 940872003 E85 Label ..................................1
48 940324014 Homelite Inquiries Label ............1
49 940803018 EMC Compliance Label ............1
50 940899002 No Oil to Gas Label ...................1
51 940947003 Combustion Label .....................1
52 941494010 Fuel Label ..................................1
53 940654089 Trigger Handle Warning Label
(French and Spanish) ................1
54 940654084 Warning Label ...........................1
55 940786006 Wand Label (Max Rating) ..........1
56 940473002 Danger Hangtag ........................1
57 940517007 Lubricant Label .........................1
58 940889002 Dip Stick Label ..........................1
59 308662001 Filter Screen ..............................1
60 308861003 Inlet Tube ...................................1
61 308862003 Outlet Tube ................................1
62 308452002 Detergent Suction Kit ................1
63 310801003 Hook and Loop Strap ................1
64 961039005 Nozzle Instructions Hangtag .....1
65 940698017 Engine Label (On-Off) ................1
66 678973001 Screw
(1/4-20 x 1.57 in., Torx T-30) .....2
Not Shown:
988000826 Operator’s Manual
(960957015) ............................. 1
988000828 Quick Reference Guide
(961458001) ............................. 1
120900147 Pump Protector
(4 oz., Not Included) ................. 1
987823001 Pump Protector
(12 oz., Not Included) ............... 1
120900148 Fuel Stabilizer (Not Included) ... 1
* High Altitude Kit 1
(Not Included) ........................... 1
* High Altitude Kit 2
(Not Included) ........................... 1
*
If you intend to operate this product at an altitude of more than 3000 ft above sea level,
please call 1-800-242-4672 to obtain one of our high altitude kits.
