HOMELITE PRESSURE WASHER — MODEL NOS. UT80522B/UT80953B
The model number will be found on a label attached to the frame. Always mention the model number in all correspondence regarding your PRESSURE
WASHER or when ordering replacement parts.
FIGURE B PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 099980425001 Cylinder Head Gasket ............. 1
2 099980425002 Cylinder Head Cover
Assembly ................................ 1
3 099980425003 Cylinder Head Cover
Gasket ..................................... 1
4 099980425004 Breather Tube ......................... 1
5 099980425005 Bolt ......................................... 4
6 099980425006 Stud ........................................ 1
7 099980425007 Stud ........................................ 2
8 099980425008 Pin ........................................... 2
9 099980425009 Cylinder Head Bolt .................. 4
10 099980425010 Spark Plug
(Champion RC12YC) .............. 1
11 099980425011 Cylinder Head Assembly
(Inc. Key No. 7) ....................... 1
12 099980425012 Stud ........................................ 1
13 099980425013 Crankcase Assembly .............. 1
14 099980425014 Engine Oil Sensor ................... 1
15 099980425015 Governor Gear Assembly ....... 1
16 099980425016 Governor Arm ......................... 1
17 099980425017 Drain Plug Bolt ........................ 2
18 099980425018 Washer .................................... 2
19 099980425019 Bearing .................................... 1
20 099980425020 Oil Seal .................................... 1
21 099980425021 Governor Gear Washer ........... 1
22 099980425022 Pin ........................................... 1
23 099980425023 Bolt ......................................... 2
24 099980425024 Crankcase Cover
Assembly ................................ 1
25 099980425025 Bearing .................................... 1
26 099980425026 Oil Seal .................................... 1
27 099980425027 Crankcase Gasket .................. 1
28 099980425028 Pin ........................................... 2
29 099980425029 Oil Dipstick Assembly ............. 1
30 099980425030 Engine Oil Plug Assembly ....... 1
31 099980425031 Bolt ......................................... 6
32 099980425032 Crankshaft Assembly .............. 1
33 099980425033 Oil Ring Set ............................. 1
34 099980425034 Piston Pin Clip ........................ 2
35 099980425035 Piston Assembly ..................... 1
36 099980425036 Piston Pin ................................ 1
37 099980425037 Connecting Rod ...................... 1
38 099980425038 First Ring ................................. 1
39 099980425039 Second Ring ........................... 1
40 099980425040 Camshaft Assembly ................ 1
41 099980425041 Exhaust Valve .......................... 1
42 099980425042 Intake Valve ............................. 1
43 099980425043 Valve Spring Seat .................... 1
44 099980425044 Exhaust Valve Retainer ........... 1
45 099980425045 Valve Rotator .......................... 1
46 099980425046 Seal Guide .............................. 1
47 099980425047 Valve Tappet ............................ 2
48 099980425048 Valve Lifter .............................. 2
49 099980425049 Lifter Stopper Plate
Assembly ................................ 1
50 099980425050 Valve Adjusting Bolt ................ 2
51 099980425051 Valve Rocker ........................... 2
52 099980425052 Valve Adjusting Nut ................. 2
53 099980425053 Valve Lock Nut ........................ 2
54 099980425054 Valve Spring ............................ 2
55 099980425055 Bolt ......................................... 4
56 099980425056 Recoil Starter Assembly ......... 1
57 099980425057 Shroud .................................... 1
58 099980425058 Cylinder Body Shroud ............. 1
59 099980425059 Lower Shield ........................... 1
60 099980425060 Oil Protector ............................ 1
61 099980425061 Stop Engine Switch
Assembly ................................ 1
62 099980425062 Bolt ......................................... 2
63 099980425063 Bolt ......................................... 1
64 099980425064 Collar ....................................... 1
65 099980425065 Bolt ......................................... 1
66 099980425066 Bolt ......................................... 4
67 099980425067 Carburetor Assembly
(Inc. Key No. 113,
UT80522B) .............................. 1
099980425134 Carburetor Assembly
(Inc. Key No. 113,
UT80953B) .............................. 1
68 099980425068 Air Cleaner Gasket .................. 1
69 099980425069 Carburetor Gasket .................. 1
70 099980425070 Carburetor Insulator Plate ....... 1
71 099980425071 Carburetor Insulator
Gasket ..................................... 1
72 099980425072 Nut .......................................... 2
73 099980425073 Air Cleaner (Inc. Key Nos.
74-75, UT80522B) .................. 1
099980425133 Air Cleaner (Inc. Key Nos.
74-75, UT80953B) .................. 1
74 099980425099 Air Cleaner Case Cover .......... 1
75 099980425101 Air Cleaner Element ................ 1
76 099980425074 Exhaust Outlet Gasket ............ 1
77 099980425075 Nut .......................................... 2
78 099980425076 Muffler Assembly
(Inc. Key No. 79, UT80522B) .. 1
099980425129 Muffler Assembly
(Inc. Key No. 79, UT80522B) .. 1
79 099980425100 Muffler Outer Cover ................ 1
80 099980425077 Fuel Tank (UT80522B) ............. 1
099980425119 Fuel Tank (UT80953B) ............. 1
81 099980425078 Fuel Strainer ............................ 1
82 099980425079 Fuel Tank Cap (UT80522B) ..... 1
099980425120 Fuel Tank Cap (UT80953B) ..... 1
83 099980425080 Fuel Tank Outlet Assembly ..... 1
84 099980425081 Collar ....................................... 2
85 099980425082 Fuel Tube ................................ 1
86 099980425083 Bolt ......................................... 1
87 099980425084 Nut .......................................... 2
88 099980425085 Nut .......................................... 1
89 099980425086 Starter Pulley .......................... 1
90 099980425087 Impeller ................................... 1
91 099980425088 Flywheel Assembly ................. 1
92 099980425089 Ignition Coil (UT80522B) ......... 1
099980425136 Ignition Coil (UT80953B) ......... 1
93 099980425090 Bolt ......................................... 2
94 099980425091 Throttle Control Assembly ...... 1
95 099980425092 Governor Spring ..................... 1
96 099980425093 Governor Rod ......................... 1
97 099980425094 Throttle Valve Return Spring ... 1
98 099980425095 Governor Support Assembly .. 1
99 099980425096 Bolt ......................................... 2
100 099980425097 Governor Support Bolt ........... 1
101 099980425098 Nut .......................................... 1
102 099980425124 Canister Cover (UT80953B) .... 1
103 099980425125 Carbon Canister (UT80953B) .. 1
104 099980425121 Rollover Valve (UT80953B) ..... 1
105 099980425122 Vapor Line (UT80953B) ........... 1
106 099980425126 Vapor Line (UT80953B) ........... 1
107 099980425128 Bolt (UT80953B) ..................... 2
108 099980425131 Air Valve Gasket (UT80953B) .. 1
109 099980425132 Muffler Air Valve (UT80953B) .. 1
110 099980425130 Bolt (UT80953B) ..................... 2
111 099980425123 Clamp (UT80953B) ................. 2
112 099980425127 Clamp (UT80953B) ................. 2
113 099980425137 Choke Lever ............................ 1
To Next Page
