HomeSeer HS-FLS100+ - Programming Z-Wave Plus Info

Sensor Event
Floodlight
behavior
Z-Wave
commands/notification
Remark
Lux
sensor
PIR
sensor
Daylight Trigger Off
When Trigger:
- Notification, PIR Trigger
ON: Group 1
When timer expire:
- Notification, PIR Trigger
OFF: Group 1
Z-Wave
command is
sent even if
floodlight is off
Night,
or
Lux knob
set to "T"
Trigger
On, until
timer
expires
When Trigger:
- Notification, PIR Trigger
ON: Group 1
- Switch Binary Report:
Group 1
- Basic Set On: Group 2
When timer expire:
- Notification, PIR Trigger
OFF: Group 1
- Switch Binary Report:
Group 1
- Basic Set Off: Group 2
Other Events
Floodlight
behavior
Z-Wave
commands/notification
Remark
1st power on
On for 5
seconds
Notification: First Power Up:
Group 1
Device Factory
reset
NA
Device Reset Locally
Notification: Group 1
Programming
Z-Wave Plus Info
Role Type
Node Type
Installer Icon
User Icon
Slave Always ON
Z-Wave Plus
node
Sensor
Notification
Device Type
(Home Security)
Sensor
Notification
Device Type
(Home Security)
Association Command Class
Group
Max Node
1
1
2
4
Version
Protocol Library
3 (Slave_Enhance_232_Library)
Protocol Version
5.3 (6.71.03)
Firmware Version
xVy (x=1, y=1 means 1V1)
Hardware Version
1
Manufacturer
Manufacturer ID
Product Type
Product ID
0x0060 (Everspring)
0x0010
0x0001
0x000C (HomeSeer) 0x0201 0x000B
AGI (Association Group Information) Table
Group Profile
Command Class & Command (List)
N bytes
Group Name(UTF-8)
1 General
Device Reset Locally Notification
Notification Report
Binary Report
Sensor Multilevel Report
Basic Report
Lifeline
2
Control
Basic Set
PIR Control
Notification Report
Event Type Event
Event Parameters
Length
Event
Parameters
First power up
0x08
0x01
0x00
PIR Trigger ON
0x07
0x08
0x00
PIR Trigger OFF 0x07 0x00 0x01 0x08
Basic Report
Parameter Number Size Range Default
4 1 0/1 1: send Basic Report
0 : not sent Basic Report
