Floodlight
remains on
PIR detector
triggered by
unknown heat
source.
1. Check time setting
2. Cover the PIR Detector with
black insulating tape. If after
the timer expires and the
floodlight turns off this
indicates that the PIR
Detector can see a moving
heat source e.g: radiator,
heater, boiler outlet, open
window, open exterior door or
moving branches or bushes
retaining heat from the
daytime period.
Manual Inclusion/Exclusion
The table below lists the several steps involved when adding or removing the unit
from the Z-Wave network.
Action/Status
Description
LED indication
No node ID
The Z-Wave Controller does not
allocate a node ID to the unit.
2-second on,
2-second off for 2
minutes.
Auto Inclusion
The power is applied for the first time
and no node ID has been stored in the
module, or after executing reset. This
process times out in 30 seconds.
LED blinks rapidly
during Inclusion, LED
stops blinking when
Inclusion is complete.
Manual
Inclusion
1. Put the Z-Wave controller into
inclusion mode.
LED blinks rapidly
during Inclusion, LED
stops blinking when
Inclusion is complete
2. Press the Link button 3 times within
1.5 seconds to put the unit into
inclusion mode.
Exclusion
1. Put the Z-Wave Controller into
exclusion mode.
2. Press the Link button 3 times within
1.5 seconds to put the unit into
exclusion mode.
Factory Reset
(This procedure
should only be
used when the
controller is
inoperable.)
1. Press the Link button 3 times within
1.5 seconds to put the unit into
exclusion mode.
2. Within 1 second of step 1, press
the Link button again and hold until
LED is off (about 5 seconds).
3. Node ID is excluded. The device
reverts to factory default state and
will be in auto-inclusion mode for 4
minutes.

Failure or success in Inclusion/Exclusion can be viewed on the Z-Wave
Controller user interface.
Specifications
PIR Tilting Angle
140∘
Mounting Height Recommended 1.8 ~ 2.0m on Normal Brick Wall
PIR Detection area
Max. distance 12m, max. angle of120°
(@1.9m height, 20°C ambient temperature)
PIR Swivel Angle Up to 90° Leftward, Up to 90° Rightward
PIR warm-up time 5 secs maximum
Lux Adjustment Approximately 30 ~ 200 Lux
Timer Adjustment Approximately 8 seconds ~ 12 minutes
Working Temperature -20°C - +40°C
Dimension (H x W x D) 60mm x 55mm x 60mm
Protection Degree IP44 – Weather proof
Specifications are subject to change without notice
