6. Release the driver’s sunvisor and passenger’s
sunvisor from the two sunvisor holders.
Q0N2013AG
Rotate.
SUNVISOR
HOLDER
SUNVISOR
HOLDER
2 SUNVISOR
HOLDERS
SUNVISOR
7. Rotate each sunvisor holders 45° counterclockwise
to remove the two sunvisor holders.
8. Pull away the driver’s door opening seal from the
driver’s A-pillar. Gently pull out the driver’s A-pillar
trim to release the clips.
Q0N2014AG
VEHICLE
PANEL
CLIP
2 CLIPS
DRIVER’S
A-PILLAR
TRIM
DRIVER’S
DOOR
OPENING
SEAL
Pull away.
CLIP
DRIVER’S
A-PILLAR
9. To prevent the clips from falling into the vehicle body,
roll up the shop towel, and insert it between the
driver’s A-pillar and the dashboard. Take care not to
damage the driver’s A-pillar.
Q0N2015BG
SHOP
TOWEL
DRIVER’S
A-PILLAR
DASHBOARD
10. Remove the driver’s A-pillar trim. Carefully remove
the shop towel and any clips that fell from the dr iver’s
A-pillar trim.
NOTE: The upper clip will stay in the body.
Q0N2016AG
UPPER CLIP
DRIVER’S
A-PILLAR TRIM
Remove.
DRIVER’S
A-PILLAR
TRIM
