Torque the spark plug. (If you do
not have a torque wrench, tighten
the spark plug two-thirds of a turn
after it contacts the cylinder head.)
Tightening torque:
Connect the wire connector to the
ignition coil. Make sure it locks in
place.
Push the ignition coil down all the
way. Install the bolt.
Repeat this procedure for the
other three spark plugs.
Reinstall the coil cover, and
tighten the four nuts.
Install the ignition coil into the
hole.
NGK:
DENSO:
8.
9.
10.
11.
12.
13.
Specifications:
Spark Plugs
Maintenance
239
13 lbf·ft (18 N·m , 1.8 kgf·m)
IZFR6K-11
SKJ20DR-M11
Tighten the spark plugs caref ully. A
spark plug that is too loose can
overheat and damage the engine.
Overtightening can cause damage to
the threads in the cylinder head.
