Pull the bulb straight out of its
socket.
Push the new bulb straight into
the socket until it bottoms.
Testthelightstomakesurethe
new bulb is working.
Put the socket back into the light
assembly and turn it clockwise to
lock it in place.
Put the cover back onto the light
assembly. Push it on until it locks
in place.
Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
Open the hatch. Remove the light
assembly cover by pushing in on
the tabs on both sides and pulling
the cover down.
1.
2.
3.
4.
5.
6.
Replacing a High-mount Brake
Light Bulb
Maintenance
Lights
263
