Unit: mm (in)
A3, a3
Corner Upper Beam Mounting
Hole ø7 (0.28)
C
F
A4, a4
Radiator Mounting
Hole ø9 (0.35)
A1, a1
Front Bulkhead Lower
Crossmember Locating
Hole ø10 (0.39)
A2, a2
Front Bumper Beam
Mounting Hole ø11 (0.43)
F
A1
A2
A3
A4
a1
752
(29.61)
1159
(45.63)
1000
(39.37)
236
(9.29)
C
a4
F
916
(36.06)
551
(21.69)
832
(32.76)
C
614
(24.17)
360
(14.17)
875
(34.45)
359
(14.13)
a3
863
(33.98)
a2
Front Bulkhead Position
4-3
