Unit: mm (in)
C
F
1186
(46.69)
A, a
Front Bumper Beam
Mounting Hole ø11 (0.43)
B, b
Front Bulkhead Lower
Crossmember Locating
Hole ø13 (0.51)
C, c
Front Subframe Mounting
Hole ø15 (0.59) front
C
F
D, d
Front Subframe Mounting
Hole ø15 (0.59) rear
E, e
Front Side Frame Gusset
Locating Hole ø28 (1.10)
C
F
F, f
Left Floor Front Extension
Locating Hole ø32 (1.26)
Right Floor Front Frame
Locating Hole ø32 (1.26)
C
F
C
F
1530
(60.24)
349
(13.74)
798
(31.42)
1779
(70.04)
1478
(58.19)
342
(13.46)
1129
(44.45)
1036
(40.79)
1029
(40.51)
895
(35.24)
1203
(47.36)
883
(34.76)
833
(32.80)
1096
(43.15)
1173
(46.18)
639
(25.16)
A
B
C
D
E
F
f
e
d
c
b
a
1045
(41.14)
1392
(54.80)
Left sideRight side
F
C
ø32
(1.26)
B
D
Engine Compartment and Front Floor, Under View
4-17
4511_3.0_enu_10319413_3.0
