Clip
#
Removal
1.
Press down on the center pin to release
the lock.
2.
Pull the clip out of the hole.
#
Installation
1.
Push the bottom of the center pin.
2.
Insert the clip into the hole.
3.
Press down on the center pin to lock the
clip.
20200227172533_31K0WA000_enu_BOOK Page 84 Thursday, February 27 2020 17:31:25 JST
Removing & Installing Body Components u Clip
Maintenance
81
Center pin
