Honda ADV150 2021 - Unlock the Ignition Switch in an Emergency

Unlock the Ignition Switch in an Emergency
#
Set up to ID number input mode
1. Use the emergency key to open the seat.
2 P. 108
2.
Remove the battery cover. 2 P. 80
3. Pull out the EM mode connector.
4. Remove the blue dummy coupler by
releasing the tab of the EM mode
connector while lifting the hook of the
blue dummy coupler.
5. Check the ID number on the ID tag.
6. Connect the EM mode coupler provided
in the tool kit to the EM mode connector.
20200227172533_31K0WA000_enu_BOOK Page 112 Thursday, February 27 2020 17:31:25 JST
Troubleshooting
109
Continued
Tab
Hook
EM mode
coupler
Blue dummy
coupler
EM mode
connector
ID number
