Removal
1. Remove the pan screws using the provided 5
mm Hex wrench (allen key).
2
P. 37
2. Remove the seat by pull it back and up.
#
Installation
1. Insert the prong into the stay on the frame.
2. Install and tighten the pan screws securely.
Make sure that the seat is locked securely in
position by pulling it up lightly.
58
Maintenance
Removing & Installing Body Components
►
Seat
Seat
Stays
Seat
Prongs
Pan screws
