Honda CB500F/FA - Rear Seat

Rear Seat
#
Removal
1. Move the seat strap forward.
2. Insert the ignition key into the seat lock.
3. Turn it clockwise, then pull the rear seat
forward and up.
#
Installation
1. Insert the tab into the recess.
2. Push down on the front of the rear seat
while inserting the ignition key into the
seat lock.
Make sure that the seat is locked securely
in position to pull it up lightly.
3. Move the seat strap to its original
position.
The seat locks automatically when closed.
20160902115018_31MJWB100_enu_BOOK Page 66 Friday, September 02 2016 11:57:25 JST
Removing & Installing Body Components u Rear Seat
Maintenance
63
Seat strap
(Original position)
Rear seat
Seat lock
Ignition key
Tab
Recess
